AMBR LE

AMBR LE™

Aquabio’s AMBR LE™ system is optimised to provide low energy use, compared with conventional crossflow or submerged membrane separation systems. By employing intermittent back flushing of membranes, fouling is controlled, enabling a reduction in crossflow velocity and a significant saving in energy. Variable speed recirculation pumps provide a variable flux rate that is used to optimise energy use relative to the plant throughput. Plants remain very compact, with low membrane area and optimal membrane replacement costs.

The cross flow ultrafiltration (UF) membranes provide a complete barrier to suspended solids resulting in a high quality, solids free permeate which can either be sent as a low cost discharge to sewer or water course or ideally applied directly to Aquabio’s RO/UV technology to provide potable water re-use.

APPLICATIONS
Low/medium flow and low/medium strength industrial wastewaters
Variable wastewater flows, high peak or seasonal loads, or when electricity costs are moderate to high
Secondary wastewater treatment to sewer or surface water
Nutrient removal, nitrification and denitrification
Combined with Aquabio’s RO/UV water re-use technology for potable/demineralised applications
AMBR Diagram 1
AMBR LE Diagram 2 Animation 2
KEY FEATURES/BENEFITS
High biomass concentration enables a smaller plant footprint compared with other systemsAutomatic Backflush - controls fouling without high scouring velocities
Deep bioreactor tank provides higher aeration efficiency and lower energy usage for UF membranesLow energy use comparable with submerged membrane systems
Low loading rate providing robust process and low sludge productionSystem can ramp-up for higher demand without additional membrane area or ramp-down to save energy at lower demand
Robust treatment for removing > 99 % COD and BODOptimised installed membrane area
‘Out-of-tank’ and low level installation of equipment provides ease and safety of maintenanceIdeal pre-treatment for direct application to Aquabio’s RO/UV water re-use technology
Modular design allows for ease of expansionAdvanced pretested, standardised software and control system
Can be easily retrofitted to existing systemsRemote access functionality
